50mm Hanging Ceiling Decoration Hollow Stainless Steel Ball

50mm Hanging Ceiling Decoration Hollow Stainless Steel Ball

50mm Hanging Ceiling Decoration Hollow Stainless Steel Ball

Overview
Quick Details
Standard:
AiSi
Grade:
300 Series
Diameter:
75mm
Application:
Decoration
Certification:
ISO
Hardness:
<=26
Place of Origin:
Guangdong, China
Brand Name:
DY
Model Number:
DY-HANDRAIL SPHERE
Color:
Optional
Magnetisim:
None
Applied technique:
Welding, molding and polishing and plating
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
50mm Hanging Ceiling Decoration Hollow Stainless Steel Ball
Our Services

Foshan Dongyuan Trading Co., Ltd. is a company dealing with a variety of products, whose major products are stainless steel and related accessories such as stainless steel valves, sculptures of all kinds of shapes as well as spheres covering many sizes. Having been in this trade for 4 years, we have succeeded in satisfying our clients and customers throughout the world for our products are of excellence and superiority. Customers’ needs are always our priority. Please rest assured that once we start meeting your requirements on any possible products we could come up with, no worries will incur about the quality, prices and all sales services. We are accountable and obligated for our customers’ comfort in terms of product quality, service and after-sales.





Company Information



We are capable of providing stainless steel spheres/balls almost as per your specific requirements. Products include hollow stainless steel spheres (ranging from 6mm to 2500mm in diameter), available for delivery if we have it in stock or delivered within 15 days. Wall thickness of spheres varies from 0.4mm to 3mm. Shaped by water pressure, our products could be mirror polished without any seams noticeable on the surface; meanwhile, welding and then sandblasting spheres is a another way to produce mirror polished spheres also without detectable traces on the spheres. Having been offering services for our customers worldwide, a variety of products also fall under many categories of our products. Staidness steel spheres, hollow or solid, of all sizes are our major products, and brass and bronze balls come along. Hollow reflective stainless steel spheres of enormous sizes are amongst the top sales in our products. Perforated stainless steel spheres or sculptures of 304 or 316 are also our hot products. Not to mention we have done considerable amount of drilled stainless steel balls or spheres with holes of many sizes. Our products are of professional and advanced technology with cost-effective craftsmanship and favorable delivery time.



Grade 304 is the standard "18/8" stainless; it is the most versatile and most widely used stainless steel, available in a wider range of products, forms and finishes than any other. It has excellent forming and welding characteristics. The balanced austenitic structure of Grade 304 enables it to be severely deep drawn without intermediate annealing, which has made this grade dominant in the manufacture of drawn stainless parts such as sinks, hollow-ware and saucepans. For these applications it is common to use special "304DDQ" (Deep Drawing Quality) variants. Grade 304 is readily brake or roll formed into a variety of components for applications in the industrial, architectural, and transportation fields. Grade 304 also has outstanding welding characteristics. Post-weld annealing is not required when welding thin sections.

Types 304 and 304L exhibit excellent resistance to corrosive environments such as the chemical, textile and petroleum industries.Type 304 and 304L are found suitable in the food and dairy industries as well as excelling in rural and industrial atmospheric exposure.By reducing the carbon content in Type 304L, welding operations will not cause carbide precipitation that can lead to inter-granular corrosion. The maximutemperature  to which Type 304 can be exposed continuously without appreciable scaling is about 1650 °F (899 °C).For intermittent cyclic exposure, the maximum exposure temperature

is about 1500 °F (816 °C).Type 304 is non-hard enable by heat treatment.Annealing: Heat to 1900 – 2050 °F (1038 – 1121 °C), then cool rapidly.Thin strip sections may be air cooled, but heavy sections should be water quenched to minimize exposure in the carbide precipitation region.Stress Relief Annealing: Cold worked parts should be stress relieved at750 °F (399 °C) for 1/2 to 2 hours.High hardness and strength  are achieved through cold working. In the annealed condition, Types 304 and 304L are very ductile and can be cold worked easily by roll forming, deep drawing, bending, and other common fabricating methods. Since the material work hardens rapidly, in-process annealing may be necessary to restore ductility and to lower hardness.

DETAILS:



Physical capability of stainless steel balls

CAPABILTY

MODEL

201

302

304

316

Tensile strength

100,000 - 180,000 psi

100,000-180,000 psi

100,000 - 180,000 psi

90,000 psi

Yield strength

50,000 - 150,000 psi

50,000-150,000 psi

50,000 - 150,000 psi

45,000 psi

Tensibility

55-60%

55-60%

55 - 60%

35%

Modulus of Elasticity

29,000,000 psi

29,000,000 psi

29,000,000 psi

28,000,000 psi

Density

280lbs/cubic inch

286lbs/cubic inch

286 lbs/cubic inch

290lbs/cubic inch




AISI NumberC %Si %Mn %Cr %Ni %Mo %P %S %Character
AISI 3020.15 Max1.00 Max2.00 Max17.0~ 19.08.0~ 10.5 0.045 Max0.03 MaxSlightly magnetic Austinitic
AISI 3040.07 Max1.00 Max2.00 Max17.0~ 19.08.50~ 10.5 0.045 Max0.03 MaxSlightly magnetic Austinitic
AISI 3160.07 Max1.00 Max2.00 Max16.5~ 18.510.5~ 13.52000~ 2.500.045 Max0.03 MaxNon magnetic Austinitic Excellent corrosion resistance
AISI 420J0.17~ 0.251.00 Max1.00 Max12.0~ 14.0  0.045 Max0.03 Maxmagnetic Hardenable HRC 48 Min fair corrosion resistance
AISI 4300.08 max1.00 Max1.00 Max15.5~ 17.5  0.045 Max0.03 Maxfair- good corrosion resistance
AISI 440C0.95~ 1.201.00 Max1.00 Max16.0~ 18.0 0.40~ 0.800.04 Max0.02 Maxfair corrosion resistance Hardenable HRC 58 Min









Packaging & Shipping

 Corrugated carton, opp bag and foam





Technology

Production Procedures







This product has many excellent properties and is suitable for a variety of applications. By creating an artistic stainless steel sculpture in your garden, we help you build up your own personalized and unique garden that stands out among the others. The product can be widely applied to different fields. By creating an artistic stainless steel sculpture in your garden, we help you build up your own personalized and unique garden that stands out among the others.
Well-known for manufacturing and supplying an extensive array of world-class Stainless Steel Products, Foshan Dongyuan limited started its operation in the year 2010. The offered product range consists of Spheres & Sculptures and much more. The stainless steel, which is best in the market, is used for manufacturing of the offered stainless steel products and fittings. Our professionals precisely engineer the offered stainless steel products and fittings in fulfillment with international quality standards. Offered by us, these stainless steel products and fittings are extremely appreciated among our patrons for their rich features such as corrosion resistant, high tensile strength, robust design, flawless finish, and durability. Offered by us, these stainless steel products and fittings can be custom designed in adherence to the set industry standards and regulations. We have been able to cater a huge clientele across the domestic markets, owing to our ability to efficiently meet the bulk demands within the assured time frame. For the purpose of maintaining the best possible quality, we have set up a well-equipped in-house quality testing unit.
